Order code TM-S3.MXDDX060B
EAN 5902052577262
Technical data
Colour (RAL)
black, RAL9005
Version
DATA2
Operating mode
M/NM
Duration
1/3 h
Protection class
II
Material
plastic
Mounting method
surface, recessed, suspended, wall, ceiling, angled
Luminance
>2 cd/m²
Luminous flux (emergency)
414(1h);184(3h) lm
Light source
LED
Light source power
3.1 W
Active power
3.6 W
Nominal AC voltage
210-250 V
LED service life
50000 h
Colour temperature
5700 K
Minimum temperature
+ 0 °C
Maximum temperature
+40 °C
Battery
LiFePO4/C (LN) 3.2V 1.5-1.6Ah
Warranty
60 months
Net dimensions L x W x H
327 mm x 40 mm x 170 mm
Installation and applications
Application
open area lighting, escape route indication
Mechanical data
IP rating
IP65
IK rating
IK08
