LLARG DWRC CT 24W GL SA LF
19339
Supply voltage type
AC
Nominal voltage (AC)
230 Vac
Supply range (min)
207 V
Supply range (max)
253 V
Frequency (min)
50 Hz
Frequency (max)
60 Hz
Power consumption EM (max)
5 W
Monitoring system
CT
Operating mode
NP/P (non-maintained / maintained)
Rest mode
Yes
Duration
1, 1.5, 2, 3, 8 h
Recharge time
12 h
Battery type
lithium iron phosphate (LiFePO₄)
Battery
LiFe 6.4V 1.5Ah
Battery included
Yes
Number of batteries
1
Duration test length
60
Duration test frequency
182
Function test frequency
28
Ambient temperature (min)
0 °C
Ambient temperature (max)
40 °C
Insulation class
I
Colour temperature
4000 K
CRI (colour rendering)
>70
Number of LEDs
1
Output SE
450, 330, 250, 160, 70 lm
Output SA
220 lm
Equivalent power
24WGL
Glow-wire resistance
850 °C - 30s.
Light sensor
Yes
Mounting
recessed, false-ceiling recessed
Environment
indoor
Areas of application
offices, public areas, retail
ATEX
No
Height
28 mm
Diameter
120 mm
Weight
0.8 kg
Cut-out diameter
80 mm
Body material
polycarbonate
Body colour
white RAL 9010
Lens material
clear thermoplastic PMMA
IP rating
IP20/IP42
IP rating (optic)
IP42
IP rating (housing)
IP20
IK rating
IK07
EAN
8002219868817
