Order code TM-TP.DFCB0100H
EAN 5902052568697
Technical data
Category
emergency luminaires
Colour finish
untreated
Version
CB – central battery
Operating mode
CB
Protection class
I
Material
stainless steel
Mounting method
surface, wall
Suitable for a pictogram
oui
Pictogram dimensions
315,6X174,6 mm
Escape sign dimensions
300x150 mm
Pictogram type
film
Luminance
>200 cd/m²
Viewing distance
30 m
Colour temperature
5700 K
Nominal AC voltage
220-240 V
Nominal DC voltage
186-254 V
Light source
LED
Light source power
0.8 W
LED service life
50000 h
Minimum temperature
-25 °C
Maximum temperature
+45 °C
Warranty
60 months
Net dimensions L x W x H
604 mm x 274 mm x 244 mm
Installation and applications
Application
escape route indication, tunnel lighting
Mechanical data
IP rating
IP66, IP69
IK rating
IK08
